It is meticulously designed for high-energy laser systems, It has a powerful powerboating capacity and can stably handle laser power in the order of hundreds of waltz, calmly dealing with high-energy inputs, In terms of beam processing. This collimator supports multimode taser beams, and the output beam quality is excellent with a uniform energy distribution. The lens group has undergone suit optimization processing, which can effectively suppress the beam diver-genre phenomenon. Even in the case of long-distance transmission, it can ensure the stability of the beam, providing a solid guarantee for the reliable operation of high-energy laser systems. It has broad application prospects in fields such as laser processing and scientific research experiments
Application
Laser processing: It is used for precision parts processing, surface treatment, composite material processing, marking and labeling
In the medical field: It is used for high-power laser surgeries and treatments, such as laser ablation and tumor treatment
Scientific research experiments: It is used in experiments that require high-power Easers, such as high-energy physics and laser spectroscopy
National defense and aerospace: Used for laser weapons, target indication, and material processing
Premium high-power substrate: suitable for high-energy scenarios
Crafted from high-power-resistant materials including fused silica lenses and large-core multimode fibers (50μm/62.5μm/100μm options), our High-power Multimode Fiber Collimator offers an exceptional laser damage threshold (LIDT >10kW/cm² @1064nm). The lens features high thermal conductivity and a low absorption coefficient, minimizing heat accumulation during high-power operation. The fiber core adopts high-purity silica with uniform refractive index profile, ensuring efficient light transmission without thermal-induced distortion. All materials undergo strict high-power laser testing to ensure resistance to thermal shock and optical degradation.
Precision high-power design: Ensuring stable performance
Our High-power Multimode Fiber Collimator is engineered with an optimized optical path and heat dissipation structure to manage high-energy laser beams. The collimator employs aspheric lenses to minimize beam divergence (0.1-0.3 mrad) and enhance beam quality for high-power applications. The metal housing (stainless steel with cooling fins) improves heat dissipation, while internal thermal conductive materials transfer heat away from optical components. The fiber connector features SMA-905 high-power design with spring-loaded ferrule for secure connection and increased pointing stability. The lens surface is coated with high-power-resistant AR coating, reducing reflection loss and preventing coating damage under high laser intensity.
Core performance advantages: Adapted for high-energy industrial scenarios
Ultraopto's High-power Multimode Fiber Collimator features a high laser damage threshold and low thermal loss, ensuring stable operation under continuous high-power laser irradiation. The collimator supports large-core multimode fibers, enabling efficient collimation of high-energy laser beams for material processing. It offers low insertion loss (≤0.5dB) and high beam uniformity. delivering consistent performance for laser cutting, welding and marking applications. The collimator exhibits excellent mechanical stability with vibration resistance up to 15g RMS, making it suitable for industrial environments. Additionally, it offers wide operating temperature range (-20℃ to 100℃) and dustproof design for harsh manufacturing conditions.
Full-scenario application coverage:
Empowering industrial laser equipment Our High-power Multimode Fiber Collimator is widely applied in industrial manufacturing and high-power laser systems. In laser cutting and welding equipment, it collimates high-power laser beams (up to 10kW) for precise material processing, achieving micron-level cutting accuracy. For laser marking and engraving machines, it delivers focused high-energy beams for permanent marking on metals and plastics. In industrial heating and surface treatment systems, it provides uniform high-power laser irradiation for material modification. The collimator also finds use in high-power laser modules, laser cladding equipment and additive manufacturing systems, delivering reliable high-energy collimation for diverse industrial applications.
Customized Services: Meeting Personalized Needs
As a leading manufacturer of high-power optical components, Ultraopto provides fully customized High-power Multimode Fiber Collimator solutions to meet your unique application requirements. Our professional R&D team can tailor key parameters including fiber core diameter (50μm-200μm), laser power handling capacity (up to 20kW), focal length (customizable), and connector type (SMA-905, etc.). FC/APC high-power variants) and lens coating. We support custom heat dissipation designs for extreme high-power applications and can optimize beam divergence for specific processing needs. All custom collimators undergo multi-stage strict quality inspection, including high-power laser testing, thermal stability assessment and beam quality measurement, with a detailed quality report provided.
Quality Assurance and Technical Support:
Your Trusted Choice Backed by advanced high-power optical technology and a complete quality control system, Ultraopto ensures stable batch supply and consistent product quality. Our production processes adhere to international industrial laser standards, with each collimator subjected to rigorous testing using high-power laser sources and thermal imaging equipment. We provide professional technical consultation on collimator selection, high-power system integration and safety compliance, helping you achieve optimal performance while ensuring operational safety. Whether you need standard collimators for laser processing or custom solutions for high-power industrial applications, Ultraopto’s High-power Multimode Fiber Collimator delivers exceptional value and reliability.
For more detailed technical parameters, product quotation information or custom design solutions for our Ultraopto High-power Multimode Fiber Collimator, please contact our professional sales and technical team through the official website, and we will provide you with efficient, personalized and professional optical solutions.
