Optical design is the core link of high-performance optical components, directly determining the performance, stability and application effect of the optical system. Ultraopto has a professional optical design team with rich experience in customized design for laser systems, imaging equipment, aerospace optics, medical optics and other fields. We provide one-stop optical design solutions from demand analysis, system simulation to design optimization and sample verification, equipped with advanced design software and testing equipment to ensure that each design scheme meets customer technical requirements. The detailed optical design processes, adopted equipment and achievable precision are shown in the following table:
Design Process | Adopted Professional Equipment & Software | Achievable Precision Index | Applicable Scenarios |
Optical System Demand Analysis | Optical system simulation software (Code V, Zemax), demand analysis platform | Demand matching accuracy: ≥99%; Wavelength matching error: ±0.3nm; System performance prediction error: ≤1% | Laser, imaging, medical, aerospace and custom optical systems |
Optical Component Design & Modeling | 3D optical modeling software (SolidWorks, AutoCAD), thin-film design software (TFCalc) | Modeling accuracy: ±0.001mm; Surface type fitting error: ≤λ/30 (@633nm); Coating layer design error: ±0.1nm | Lenses, prisms, filters, mirrors, windows and custom optical components |
Optical Performance Simulation & Optimization | Zemax OpticStudio, Code V, ray tracing simulation system | Imaging resolution: ≥100 lp/mm; MTF value: ≥0.8 (at 50 lp/mm); Aberration correction: ≤0.002λ; Light transmission efficiency: ≥99.5% | High-precision imaging systems, laser transmission systems, optical detection systems |
Design Scheme Verification & Adjustment | Zygo interferometer, spectrophotometer, optical performance test platform | Verification accuracy: ±0.001mm; Performance deviation: ≤0.5%; Adjustment response time: ≤24h | All customized optical design schemes and sample verification |
Design Documentation & Technical Support | Technical documentation editing software, design database management system | Documentation accuracy: 100%; Technical parameter description error: 0; After-sales support response: ≤12h | All optical design projects, mass production technical guidance |
Core Advantages of Ultraopto Optical Design
Professional Design Team:
The team has more than 10 years of optical design experience, proficient in various optical system design, and can quickly respond to customized needs of different industries.
Advanced Design Tools:
Equipped with international top optical design and simulation software, combined with professional testing equipment, to ensure the accuracy and feasibility of design schemes.
Full-chain Design Service:
Provide one-stop service from demand analysis, design, simulation, verification to mass production guidance, reducing customer project cycle and cost.
Strong Compatibility:
The design scheme is fully compatible with the company's precision processing and coating capabilities, ensuring that the designed products can be stably mass-produced with high precision.
Industry-specific Solutions:
Customize targeted optical design schemes for aerospace, laser, medical and other high-end fields, meeting the harsh application environment requirements.
